3P32A IP44 Industrial waterproof plug
sockets,250V,industrial plug

Suitable range
This industrial sockets can be widely used in industry, agriculture, chemistry, airports, docks, ships, electricity, construction, profits and other internal and external places.

industrial sockets mix
This industrial sockets is in accordance with the national standard GB/T 11918.1-2014; GB11918.2-2014;Designed and produced, the product specification is FNP2-023 3pin 32A 250V industrial plug, the plug is 2P+E, the range is 250V, and the product protection level is IP44 Splashproof.

Key material parameters
· Shell material: PA flame retardant nylon
· Material of current-carrying flange: PA flame retardant nylon
· Contacts/screw accessories: copper /ML08A cold heading steel

industrial sockets technical feature
· Rated current: 32A
· Rated voltage: 250V
· Protection degree: IP44 Splashproof
· Insulation resistance: 500V d.c not less than 5 μΩ
· Dielectric strength: 2500V
· Temperature rise: the current-carrying end shall not exceed 50K
· Electrical clearance: not less than 8 mm
· Creep distance: not less than 10mm
· Heat and flame resistance: current-carrying parts 850 15℃; 650+/-15℃ for shell parts
· Cable connection end bears tension: not more than 80N

Industrial sockets outline installation ruler diagram
32A 2P+E 6H 220-250V IP44 Splashproof
