5P16A IP44 Industrial waterproof plug
Minimum order quantity:
1 piece
Country of Origin:
industrial plug
Contact Now
add to cart
FNP2-015 5p 16a IP44 waterproof Industrial plug
5p 16a Industrial Socket and Plug IP44 415V Waterproof
Suitable range
This industrial plug can be widely used in industry, agriculture, chemistry, airports, docks, ships, electricity, construction, profits and other internal and external places.
5p 16a industrial plug mix
This industrial plug is in accordance with the national standard GB/T 11918.1-2014; GB11918.2-2014;Designed and produced, the product specification is FNP2-013 5p 16a 250V industrial plug, the plug is 3P+N+E, the range is 250V, and the product waterproof protection level is IP44.
Key material parameters
· Shell material: PA flame retardant nylon
· Material of current-carrying flange: PA flame retardant nylon
· Contacts/screw accessories: copper /ML08A cold heading steel
industrial plug technical feature
· Rated current: 16A
· Rated voltage: 250V
· Protection degree:  IP44 waterproof
· Insulation resistance: 500V d.c not less than 5 μΩ
· Dielectric strength: 2500V
· Temperature rise: the current-carrying end shall not exceed 50K
· Electrical clearance: not less than 8 mm
· Creep distance: not less than 10mm
· Heat and flame resistance: current-carrying parts 850 15℃; 650+/-15℃ for shell parts
· Cable connection end bears tension: not more than 80N
5p 16a waterproof Industrial plug installation ruler diagram
5p 16a 3P+N+E 6H 220-250V waterproof IP44 industrial plug
5p 16a Industrial Socket and Plug IP44 415V Waterproof
