FNP2-114 3P16A IP44 Industrial waterproof socket

Suitable range

This industrial plug can be widely used in industry, agriculture, chemistry, airports, docks, ships, electricity, construction, profits and other internal and external places.



industrial plug mix

This industrial plug is in accordance with the national standard GB/T 11918.1-2014; GB11918.2-2014；Designed and produced, the product specification is FNP2-013 3pin 16A 250V industrial plug, the plug is 2P+E, the range is 250V, and the product protection level is IP44 Splashproof.



Key material parameters

· Shell material: PA flame retardant nylon

· Material of current-carrying flange: PA flame retardant nylon

· Contacts/screw accessories: copper /ML08A cold heading steel



Technical feature

· Rated current: 16A

· Rated voltage: 250V

· Protection degree: IP44 Splashproof

· Insulation resistance: 500V d.c not less than 5 μΩ

· Dielectric strength: 2500V

· Temperature rise: the current-carrying end shall not exceed 50K

· Electrical clearance: not less than 8 mm

· Creep distance: not less than 10mm

· Heat and flame resistance: current-carrying parts 850 15℃; 650+/-15℃ for shell parts

· Cable connection end bears tension: not more than 80N



Outline installation ruler diagram

16A 2P+E 6H 220-250V IP44 Splashproof



• Application：

  Industrial
• Rated Current：

  16A
• Rated Voltage：

  220V
• Grounding：

  Other
• Type：

  Electrical Plug
• Model Number：

  FNP2-114
• Brand Name：

  NANTE
• Place of Origin：

  China
• Industrial plug and socket：

  Open socket
• industrial plug：

  nante FNP2
